1.5 2 2.5 3 Ton Battery Forklift with 48V 80V Accumulator and Charger

Product Description

We HELI Group (Anhui HELI Co., Ltd) was founded in 1958, for the last 57 years, we only specialize in manufacturing and selling forklifts. From 1991, we has been No.1 in China for 26 years; from 2013, we rank No.8 in the world. We have 8000+ employees and 800 technician engineers, we make and sell forklifts 86000 units each year. We have established mature dealership in more than 150 countries and regions.
We supply forklift with:
High-level Quality (largest forklift manufacturer)
Competitive Price, LOW Price (largest forklift exporter)
Best After-sale Service (sell to 150 countries and regions)

1.5 2 2.5 3 Ton Battery Forklift with 48V 80V Accumulator and Charger

1.5 2 2.5 3 Ton Battery Forklift with 48V 80V Accumulator and Charger

Standard Configuration of our 1.5/2/2.5/3ton Electric Battery Forklift
1.American Curtis Controller
2.Advanced HELI Hydraulic Automatic Transmission
3.Electric-hydraulic Directional Control Valve
4.AC Motor, Larger Power
5.Lifting Height 3000mm, Duplex Mast
6.Pneumatic Tyres
7.Fork Length 920mm/1070mm
8.Comfortable Seat with Armrest and Safe-belt, etc.
Optional Equipments
1.Italian Zapi Controller
2.Lifting Height 3m-7m
3.Full-free Duplex or Triplex Mast
4.Side Shift, Solid Tyres, No-mark Solid Tyres, Suspension Seat
5.Driver's Cabin, Customized Color, etc.

1.5 2 2.5 3 Ton Battery Forklift with 48V 80V Accumulator and Charger

General	Manufacture		1.5 2 2.5 3 Ton Battery Forklift With 48V 80V Accumulator Charger
	Model Designation		CPD20-HA-2	CPD25	CPD30
	Load Capacity	kg	2000	2500	3000
	Load Center	mm	500	500	500
	Power Type		Battery	Battery	Battery
Size	Height with Mast Lowered	mm	2000	2000	2075
	Free Lift	mm	170	170	145
	Standard Lift Height	mm	3000	3000	3000
	Height with Mast Extended	mm	3995	3995	4182
	Overhead Guard Height	mm	2130	2130	2215
	Fork Size	mm	45×100×920	45×100×1070	45×125×1070
	Fork Carriage to DIN 15173 A/B		2A	2A	3A
	Length to Fork Face	mm	2398	2398	2485
	Wheelbase	mm	1515	1515	1680
	Overall Width	mm	1150	1150	1225
	Total Approximate Weight(W/O battery)	kg	4050	4200	4810/3230
	Mast Tilt Angle(F/R)		6/12	6/12	6/12
	Outside Turning Radius	mm	2065	2065	2210
	Ground Clearance at Mast (Loaded)	mm	140	140	135
	Ground Clearance at Centre of Wheelbase (Loaded)	mm	155	155	150
Performance	Travel Speed (with/without load)	km/h	14/15	14/15	15.0/15.5
	Lifting Speed (with/without load)	mm/s	280/490	260/490	280/450
	Lowering Speed	mm/s	450	450	500
	Gradient Performance (Loaded)	%	16	15	15
	Max.Draw Bar Pull (Loaded)	N	12300	12800	15600
Tyres	Tyre Type		Pneumatic	Pneumatic	Pneumatic
	Tyres Number (Front/Rear)		2/2	2/2	2/2
	Tread (Front/Rear)	mm	960/950	960/950	1000/980
	Tyre Size (Front)		7.00-12-12PR	7.00-12-12PR	28×9-15-12PR
	Tyre Size (Rear)		18×7-8-14PR	18×7-8-14PR	18×7-8-14PR
Battery	Battery Voltage/Rated Capacity(5h)	V/Ah	48/600	48/600	80/480
	Battery Weight	kg	1125	1125	1580
	Compartment for Battery Size	mm	525×1050×807	525×1050×807
Motor & Controller	Drive Motor-60 Min. Rating	kw	11.1(AC)	11.1(AC)	16.6(AC)
	Pump Motor-15 Min.Rating	kw	10.5(DC)	10.5(DC)	13(DC)
	Drive Motor Control Method		MOSFET/AC	MOSFET/AC	MOSFET/AC
	Pump Motor Control Method		MOSFET/DC	MOSFET/DC	MOSFET/AC

Quality Advantage
For our 1.5 2 2.5 3 ton battery forklift with 48v 80v accumulator charger:
1. Larger Battery, High-level Battery
For our 2ton 2.5ton forklift, our battery is 48V/600Ah, larger battery, long service time..
Our battery is from one of leading battery manufacturers in China, high-level quality, long service life.
2. We use Japan Germany Transmission
   All key parts are imported from Japan and Germany.
Others all use China made transmission. All gears are made in China.
3. We use Japan Hydraulic System (gear pump, cylinder, high-pressure oil pipe)
   Others all use normal China made pump pipes.
4. We use High Frequency Charger
Save much charging time for you.
5. We use Reliable & Flexible Casting Steering System
   Now global top forklift brands all use casting steering system, while other China brands still use traditional welding axle. Casting type is stronger, and low maintenance cost than welding axle.

LOW PRICE, sell to 150 countries
High-level Quality (the largest forklift manufacturer in China)
  We have toppest forklift engineers team in China, with the biggest forklift R&D base.
All spare parts our forklift use must standard at least two technical tests, to make sure reliability.
LOW Price (mass production)
Every year we make and sell more than 86000 units forklift to China and world.
We are the largest forklift manufacturer, mass production largely lower our pruduction cost.
So our price of forklift is lower, but high level quality.
The largest forklift exporter, Selling to more than 150 countries and regions
  As the largest forklift exporter, we have sold our forklifts to more than150 countries and regions, every year we export 16000+ unit to the world market.
Reliable After-sale Service
We HELI Group only choose long cooperation suppliers, this largely avoid the risk of breakdown in parts supply chain.
With years' development, we have established mature dealership and service shop in more than 150 countries and regions. It's very easy to buy our spare parts and get maintenance cost in your local. While other brand can't do this.
The price of our forklifts are low, we also will save more maintenance cost for you in the future.

Company Introduction
We HELI Group (Anhui HELI Co., Ltd) was founded in 1958, for the last 57 years, we only specialize in manufacturing and selling forklifts.
From 1991, we has been No.1 in China for 26 years; from 2013 to now, we rank No.8 in the world.
We have 8000+ employees and 800 technician engineers, we make and sell 86000 units forklift each year.
In China, we have the largest forklift R&D base, and the largest forklift testing center.
We have high cooperation with global famous R&D team and office in Italy, Japan, Germany, American, etc.
We have established mature dealership in more than 150 countries and regions.
We supply high level quality forklift with low price.
1.5 2 2.5 3 Ton Battery Forklift with 48V 80V Accumulator and Charger

We supply full range Forklift Trucks
Diesel Forklift: 1.5 ton, 2 ton, 2.5 ton, 3 ton, 3.5 ton, 4 ton, 4.5 ton, 5 ton, 6 ton, 7 ton, 7.5 ton, 8 ton, 10 ton
Gasoline/Lpg Forklift: 1.5 ton, 1.8 ton, 2 ton, 2.5 ton, 3 ton, 3.5 ton, 4 ton, 4.5 ton, 5 ton, 6 ton, 7 ton
Electric Forklift: 1 ton, 1.5 ton, 1.8 ton, 2 ton, 2.5 ton, 3 ton, 3.5 ton, 4 ton, 4.5 ton, 5 ton, 6 ton, 7 ton
Heavy Duty Forklift: 12ton, 13ton, 14ton, 15ton, 16ton, 18ton, 20ton, 25ton, 32ton, 46ton
Electric Stacker, Electric Pallet Truck
Full-electric Stacker: Loading Capacity 1000kg, 1200kg, 1400kg, 1600kg, 2000kg
Electric Pallet Truck: Loading Capacity 1500kg, 2000kg, 2800kg, 3000kg, 3500kg.
Which one do you need? Send inquiry now.
For more information about our 1.5 2 2.5 3 ton battery forklift with 48v 80v accumulator charger, Contact Us Now!
