3 Ton Forklift for Sale

Product Description

High quality:

'--Adopt gradeability improving style electronic hydraulic transmission,compare with other models:efficiency 5% improved,climbing torque 8% increased,noise 3~5dB reduced,thermal equilibrium temperature 8-10°decreased; --The super large capacity aluminum tube belt radiator and optimized heat dissipation channel further improve the heat dissipation capacity of the vehicle; --Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system, save energy and improve operation comfort.

High security:'

--Introducing advances technology from Germany,the unique single chain has greatly enhanced he front view while working. --All car LED lights, high brightness, long life, energy saving and environmental protection.

High comfort:

'--The new suspension system,adjustable seat,allowing the driver to feel more comfortable and reducing fatigue during long operations;' --The combined color instrument has strong human-machine interaction and timely and accurately feedback the running state of vehicles.

--Spacious control space, comfortable seats, enjoy the pleasure of riding.

Rich options:

ISUZU engine, high exhaust device, air prefilter, fireproof cap, solid tire, two stage free lift mast, three stage free lift mast , widening fork frame, fork sleeve, side shifter, paper roll clamp, bale clamp, carton clamp, block clamp, rotators, drum clamp, push-pull, etc.

Product Paramenters

Model			UNIT	SA530
Specifications	Power Unit			Diesel
	Operator Type			Driver/Seat
	Transimission Box Type			Automatic Transimission
	Rated Capacity		kg	3000
	Load Center		mm	500
	Max.Lifting Height		mm	3000
	Tire Type			Pneumatic Tire
	Tire Number	Front		2
		Rear		2
	Tire Size	Front		28×9-15-14PR
		Rear		6.5-10-10PR
Performance	Lifting Speed	Loaded	mm/s	480
		Unloaded		500
	Lowering Speed	Loaded	mm/s	420
		Unloaded		400
	Travelling Speed	Loaded	km/h	20
		Unloaded		21
	Max.Gradeability (Loaded)		%	20
	Max.Drawbar Pull (Loaded)		kn	17
	Mast Tilting Angle (Fwd/Bwd)		deg	6/12
	Free Lifting Height		mm	150
	Turning Radius		mm	2395
Dimensions	Overall Length (with fork)		mm	3800
	Overall Width		mm	1240
	Overhead Guard Height		mm	2145
	Fork Size (LxWxT)		mm	1220×125×45
	Mast Height (Fork lowered)		mm	2140
	Battery (Voltage/Capacity)		V/Ah	12/90
	Truck Weight		kg	4250
	Fuel Tank Capacity		L	70
Engine	Brand			XINCHAI	ISUZU
	Model			C490	C240
	Rated Power		kw/rpm	40/2650	35.4/2500
	Rated torque		n-m/rpm	160/1600-2000	137.7/1800
	Number Of Cylinder			4	4
	Displacement			2.67	2.37
