China 2.5t 4X4wd Heavy Duty Telehandler with Cummins Engine

Product Description

Introduction:

HNT40-4 Type Telescopic Forklift Loader, which uses the four-wheel drive, the rigid suspension; The fluid mechanical drive, the hydraulic power changes with the hydraulic brake, the rear wheel changes. The operation installment is two quadrangle telescopic handle, has fork which fix could be side to move. Could use to pull in & out the box on the container, also for loading and unloading, Cargo stowing and short-haul handing.

This type could be operated under many kinds of working conditions, is excellent equipment for craning, transporting, loading and unloading on Industry and Mining, Enterprise, Construction, Materials, Harbor, Municipal Engineering. Also has the scoop, the hook, the suspend arm and so on each kind is differently for the customer's choice to install. Its loading and unloading and the cross-country performance is highly the universal forklift is unable to compare.

Technical Paramters:

Item		Unit	HNT25-4
Rated lifting capacity		kg	2500
Max. lifting height		mm	7000
Max. lifting height		mm	7000
Max. outreach		mm	3350
Max. outreach		mm	3350
Max. driving speed		kw/h	30
Min. ground clearance		mm	400
Deadweight		kg	9510
Wheel tread		mm	1870
Wheelbase		mm	2700
Overall dimensions	Height	mm	2485
	Width	mm	2390
	Length	mm	5730(with fork)
	Inner width of the cab	mm	720
	Fork size	mm	100015050
Engine	Model	DF CUMMINS	4BTA3.9-C80
	Rated power	kw	60
	Rated speed	r/min	2200
	Displacement	L	3.9
Tyre	Front wheel		16/70-24
Tyre	Rear wheel		10.00-20
