China Famous Brand Yto 1.5t Electric Mini Forklift Truck Cpd15 Good Price

Product Description

China famous brand YTO 1.5t electric mini forklift truck CPD15 good price

Specifications
China famous brand YTO 1.5t battary forklift truck CPD15 price
Power type Battary
Rated capacity 1.5ton
Motor 5-7.5kw
1.5ton forklift China YTO DC Motor forklift truck CPD15
Power type Battary
Rated capacity 1.5ton
Motor 5-7.5kw

Specification

Speciality parameter	Model					CPD15
	Power type					Battery
	Rated capacity				kg	1500
	Load center			d	mm	500
	Lift height			h2	mm	3000
	Mast tilt angle (forward/backward)			α/β	Deg	6/12
	Front overhang			L3	mm	425
	Wheel-base			L4	mm	1370
	Tread(front/rear)			b4/b5	mm	890/920
Performance parameter	Travel brake					Hydraulic-Foot pedal
	Parking brake					Mechanical-Hand level
	Lift speed(with/without load)				mm/s	260/380
	Lower speed (with/without load)				mm/s	laden<600without load>300
	Travel speed (with/without load)				km/h	11/13
	Max. gradeability (laden)				%	15
	Max. Towing (with/without load)				kN	6/5
	Weight Distribution with load(front/rear)					3350/500
	Weight Distribution without load(front/rear)					1200/1650
Power, transmission and others	motor	Driving motor	Model			XQ-5-T
			Rated power		kw	5
			Rated rotation		r/min	1480
		Working motor	Model			XQD-7.5-C
			Rated power		kw	7.5
			Rated rotation		r/min	1550
	Controller	Manufacturer				GE
	Controller	Type				MOSFET
	Battery	Voltage			V	48
		Capacity			Ah	550
		Size(L×W×H)			mm	725×982×500
	Gearbox	Transmission type				Mechanical
	Tyre	type				Pneumatic tyres
		Model	Pront			6.50-10-10PR
		Model	Rear			16×6-8-10PR
Others	Dead.weight				kg	2850
	Free lift height			h4	mm	135
	Fork	Thickness×Width×Length		c×b×a	mm	35×100×920
	Overall dimensions	Overall length(without forks)		L2	mm	2070
		Overall width		b1	mm	1070
		Overall height	Extended height(mast)	h1	mm	4020
			Lowered height (mast)	h3	mm	1995
			Overhead guard	h7	mm	2130
	Min. turning radius			Wa	mm	1950
	Min. under ground clearance	Under mast		m1	mm	110
	Min. under ground clearance	Center of wheel-base		m2	mm	105
