Product Description

Manufacturer			RY
	MODEL		T25Y	T30Y	T50P
General	Power Type		DIESEL	DIESEL	DIESEL
	engine		YANMAR	YANMAR	/
	Rated Load Capacity	kg	2500	3000	5000
	Load Centre	mm	500	500	600
Characteristic & Dimension	Rated Lift Height	mm	3000	3000	3000
	Free Lift Height	mm	150	150	/
	Mast Tilt Angle (F/R, α°/β°)	Deg	10º/12º	10º/12º	15º/15º
	Mast Lowered Height	mm	1980	2270	2565
	Mast Extended Height (With Backrest)	mm	4015	4335	4016
	Overhead Guard Height	mm	1980	2275	2545
	Ground Clearance (Bottom of Mast)	mm	220	270	320
	Length to Face of Fork (Without Fork)	mm	2997	2997	2997
	Overall Width	mm	1600	1600	2067
	Fork Size (L×W×T)	mm	1220X125X50	1220X125X50	1220X150X50
	Fork Overhang (Wheel Center to Fork Face)	mm	606	606	732
	Rear Overhang	mm	540	540	740
	Turning Radius (Outside)	mm	2785	2785	3516
	Min.Right Angle Stacking Aisle Width (Add Load Length and Clearance)	mm	4805	4805	/
Performance	Travel Speed (No Load)	km/h	22	22	22
	Travel Speed (Full Load)	km/h	22	22	/
	Lifting Speed (Full Load)	mm/s	450	450	570/500
	Lowering Speed (Full Load)	mm/s	500	500	500
	Max.Drawbar Pull (Full Load)	KN	17	17	17
	Max.Gradeability (Full Load)	%	16	16	30/32
	Service Brake (Operation/Control)		Foot/Powershift	Foot/Powershift	Foot/Powershift
	Parking Brake (Operation/Control)		Hand/Mechanical	Hand/Mechanical	Hand/Mechanical
