China Topwin Forklift Truck 1.5ton 2ton 2.5ton 3ton 3.5ton New Electric Forklift Diesel Forklift LPG Forklift with CE

Product Description

Topwin Forklift Truck 1.5ton 2ton 2.5ton 3ton 3.5ton New Electric Forklift Diesel Forklift LPG Forklift with CE

Standard configs.:
1.0Ton Diesel Forklift Truck
1 stage 1.34M Mast
Hydraulic transmission (Automatic),
1.07m fork,
China Engine 485BPG 30KW,
Pneumatic tyre,
Seat with safety belt & steady bar Warning light

Main specs.:

General	Model		CPCD10FR	CPCD20FR	CPCD25FR	CPCD30FR	CPCD35FR
	Rated capacity	kg	1000	2000	2500	3000	3500
	Load center	mm	500	500	500	500	500
	Power type		Diesel	Diesel	Diesel	Diesel	Diesel
	Transmission		Hydraulic/Mechanical
Dimensions	Lifting height	mm	1350	3000	3000	3000	3000
	Free lifting height	mm	1350	60	60	80	80
	Turning radius	mm	2010	2450	2450	2500	2500
	Overall length	mm	3365	3605	3605	3800	3800
	Overall width	mm	1095	1160	1160	1230	1230
	Overall height (mast lowered)	mm	2038	2095	2095	2110	2110
	Overall height (mast raised)	mm	2038	4080	4080	4270	2110
	Overall height (overhead guard)	mm	2038	2095	2095	2110	125
	Fork length	mm	1220	1070	1070	1220	1220
	Fork width	mm	90	100	122	125	125
	Fork thickness	mm	35	40	40	45	50
Performance	Max. driving speed (with/without load)	km/h	13.5/14	17/19	17/19	18/20	17/19
	Max. lifting speed (with load)	mm/s	500	400	400	400	375
	Max. traction (with/without load)	kn	/	14/9	15/10	15.5/10.5	16/11
	Gradeability (with/without load)	%	15/20	15/20	15/20	15/20	15/20
	Tilting angles (forward/backward)	°	6/12	6/12	6/12	6/12	6/12
	Service weight	kg	1770	3320	3600	4320	4580
Engine	Engine model		485BPG	490BPG	490BPG	490BPG	490BPG
	Power	kw	30	37	37	37	37
	Rated speed	rpm	2600	2500	2500	2500	2500
Wheel	Front overhang	mm	385	451	451	465	465
	Wheel base	mm	1420	1640	1640	1750	1750
	Front tread	mm	900	970	970	1000	1000
	Rear tread	mm	930	970	970	970	970
	Front tire		6.50-10	7.00-12	7.00-12	28x9-15	28x9-15
	Rear tire		5.00-8	6.00-9	6.00-9	6.50-10	6.50-10

Company details:
Shandong Topwin Machinery Co.,Ltd. (TOPWIN for short) is the one-stop solution provider for construction machinery, mining machinery, agricultural machinery and logistic machinery in China.

With more than 10 years experience in this field, TOPWIN has served various clients from USA, Canada, Mexico, Brazil, Argentina, Australia, Indonesia, Kazakhstan, Russia, Zimbabwe, Mozambique, Zambia, South Africa, etc.. We are helping our clients to succeed in every project by offering high cost-effective and reliable machines.

TOPWIN has enjoyed great reputations in road constructions, mining operations, farming, fertilizer manufacturing, etc.. That's why we get repeat purchases and more new clients from different countries and regions.

TOPWIN values high quality products and immediate response to clients' demand. We know how important it is for client to have a product that not only keeps on doing its job throughout the day, but also keeps on doing so for many years.

We offer full guidance to service and maintenance to make sure the machines are running normally with maximum productivity. To achieve that, we provide the clients with full support from day one.
