Shacman F2000 9m3 Capacity 290HP Concrete Mixer Truck
Shacman concrete mixer truck 6m3 8m3 10m3 12m3 capacity Contatc: AllanMobile:+8615958955352 Basic InformationChassis modelSX5255GJBJR404CabFlat head ,single row with one berthDrive positionLeft hand driveOver Dimensions(L×W×H)(mm)9995×2500×3985Curb mass(kg)......
Send Inquiry
Product Description
Mobile:+8615958955352
Basic Information | Chassis model | SX5255GJBJR404 |
Cab | Flat head ,single row with one berth | |
Drive position | Left hand drive | |
Over Dimensions(L×W×H)(mm) | 9995×2500×3985 | |
Curb mass(kg) | 13700 | |
Wheelbase(mm) | 3975+1400 | |
Drive style | 6x4 | |
Tread(front/rear)(mm) | 2036/1850/1850 | |
Approach/Departure angle(°) | 20/19 | |
Air condition | Yes | |
Leaf-spring system | 9/12 | |
Maximum speed (km/h) | 77 | |
Engine | Engine model | WP10.340E32 |
Manufacturer | Weichai power Co.,Ltd | |
Displacement(ml)/Power(HP) | 9726/340 | |
Emission standard | Euro 3 | |
Fuel type | DIESEL | |
Gear box | Fast brand 9JS119, 9 forward gear and 1 reverse gear | |
Tyre | Tire specifications | 318/80/R22.5 |
Number of tyres | 10+1 Spare tire | |
Mixing drum | volume of mixer | 12m3 |
Rotating speed | 6-12r/min | |
Feed rate(m3/min) | ≥3 | |
Discharge(m3/min) | ≥2 | |
Discharge residual percentage | ≤0.7 | |
Water supply system | Type of water supply | air pressure |
