Product Description

China AOTONG trailer manufacturer High Quality Animal Transportation Trailer Box/Van Truck Semi Trailer, Cargo/Electronic Appliance Transportation(step-wise optional, 5 doors on each side)

Discription:
1. Model: LAT9280XXY
2. More than 16 years professional manufacturer experience
3. Be designed according to your requirements
4. CCC ISO9001 agreement
5. Small order can be accepted
6.12 month quality guarantee term
7. We accept 100% inspection, welcome to our factory at any time

This van semi trailer is applicable to the transportation of the household appliance, textile goods, coal, dinas, and other building materials.

Product Specifications
Model Number	LAT9280XXY
Rated Load	35000 kg
Tare Weight	7000 kg
Wheel Base	6900+1310+1310 (mm)
Tyre Specifications	1100R20-18/12R22.5-18
No. Of the Tyres	12
Axle Brand	FUWA (BPW optional)
No. Of the Axles	3
King Pin	50#/90#
Landing Leg	28ton
Pieces of leaf-spring	10
Suspension	is constitute by tandem steel plate spring and bearing legs.
Departure Angle	13.1
Front/Rear Overhang	2390 mm
Outside Dimensions (LxWxH)	13000X2500X4000,3900,3700,3500 (mm)
Interior Dimensions (LxWxH)	12850X2300X2300,2200,2000,1800 (mm)
Material of the Main Beam	Q345B manganese plates, automatic submerged arc welded
Brake System	Dual line braking system /ABS
Brake Air Chamber	Six double chamber
Electrical	24V 7 ways(7 wire harness)
Usage	Applicable to the transportation of the household appliance, textile goods, coal, dinas, and other building materials.
Other Descriptions	box shell uses the corrugated steel plate (anti-wave) or flat type steel plate with high intensities. The interior part adopts a skeletonless structure, maximizing the carrying capacity. X-shape tension brace fixed the box shell a very strong unit. The side guard adopts close-ended design to reduce the crosswise risks effectively, and energy consumption, running with high speed. And reasonable trailer accessories were placed at the rear guard box for convenience.
Other Specifications	The top of the box is be close-ended (pull/push open-ended, open-type, or open-type with cloth tent poles optional) The max height of the rear guard from ground is 550mm, and the cross section is 160mmX40mm.

Company Information:

Qingdao Juyuan International Trading Co., Ltd. is an industry & trade company, with a factory, Liangshan Juyuan Special Vehicle Manufacturing Co., Ltd.

With advanced and proven technique in design, exploitation and production, our products with the brand "Aotong" are enjoying high popularity in America, the Middle East, Africa, Southeast Asia and Russia,specially get good feed back from Kenya,Tunisia,Saudi Arabia, the Philippines, Myanmar, Vietnam, Thailand, Bangladesh, Tanzania, mozambique, Congo, Nigeria, Russia, Singapre,South Korea etc.  .
Now we provide more than 60 types of trailers. Our production can be done according to your requirements.

    DEALING PROCESS OF COOPERATION

1. Send us inquiries on your desired product / mdel through our contact information.
2. We shall reply you within 12 hours.
3. Negotiations on your needed configuration.
4. Configuration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updated news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.

Wordwide supplier of special vehicle semi truck trailer series,lowbed trailer,container chassis,platform trailers,fuel tank trailers and more!

AOTONG trailer,your wise choice.Contact us today!

Pls contact leo wang for details, good quotation and further product information will be provided as required. We will be 24 hours on line, waiting for your kind inquiry.

Welcome to visit our factory,we will pick you up from the airport or station.

Looking to import to Melbourne Australia tandem trailers for cars looking at starting to sell them here so need good price and someone who will supply me

CONTACT:
24 hours on line ,waiting for your kind inquiry
Please contact Lotus Ho for details.
Phone: +86 13969627783

Website:http://juyuanguoji.en.made-in-china.com
