Trailer Truck Air Chamber T30/30
Product DescriptionFeatures:1. Stroke:64/64mm Bolt Center: 120.7mm 2. Port thread: M16*1.5 3/8"NPT 3/8"NPT 3. Bolt Thread: M16*1.5 M16*1.5 5/8"UNC 4. Push Rod: M16*1.5 M16*1.5 5/8"UNF 5. Total Push Rod Length:285mm 6.T12/20, T16/24, T24/24, T24/30 are ......
Send Inquiry
Product Description
Product Description
Features:
1. Stroke:64/64mm Bolt Center: 120.7mm
2. Port thread: M16*1.5 3/8"NPT 3/8"NPT
3. Bolt Thread: M16*1.5 M16*1.5 5/8"UNC
4. Push Rod: M16*1.5 M16*1.5 5/8"UNF
5. Total Push Rod Length:285mm
6.T12/20, T16/24, T24/24, T24/30 are also available.
Descriptions:
Features:
1. Stroke:64/64mm Bolt Center: 120.7mm
2. Port thread: M16*1.5 3/8"NPT 3/8"NPT
3. Bolt Thread: M16*1.5 M16*1.5 5/8"UNC
4. Push Rod: M16*1.5 M16*1.5 5/8"UNF
5. Total Push Rod Length:285mm
6.T12/20, T16/24, T24/24, T24/30 are also available.
Descriptions:
| Model | RM# | Description | |||||
| Stroke | Air inlet thread | Bolt thread | Bolt center | Pushrod thread | Pushrod length | ||
| T30/30DD | QS3030A | 64 | 2-NPT3/8 | 2-M16 x 1.5 | 120.7mm | M16 x 1.5 | 285mm |
| QS3030B | 64 | 2-NPT3/8 | 2-5/8-11UNC | 120.7mm | 5/8-18UNF | 285mm | |
| QS3030C | 64 | 2-M16 x 1.5 | 2-M16 x 1.5 | 120.7mm | M16 x 1.5 | 285mm | |
