Vehicle Transport Trailer/Car Carriers Semi Trailer

Product Description

Vehicle Transport Trailer/Car Carriers Semi Trailer

1. This system mainly adopts the transportation vehicles semi-trailer rectangular pipe welded together frame structure, the overall high intensity, light weight, good appearance, have fully enclosed type, half hanging, semi-enclosed and frame type to wait for a few kinds structure, the use of safe and reliable.
2. The model fully absorbed the features of similar domestic and foreign products, adopt unique lifting system, the key part adopts renowned domestic and foreign products, load ability and high reliability
3. The whole upper platform can be used on a certain height, thus the car can carry a different specifications of cars, MPV and SUVs and pickup truck, miniature passenger vehicles such as 5-10 vehicles. User's special customized vehicles can possess such special vehicle smoked pull function, can transport various kinds of automobiles, return distribution, and other functions. The car is realized commodity car sales ideal tool for zero miles per hour.

Trailer Model	2 Axles car/vehicle carrier semi trailer
Overall Dimension(Lx W x H)(mm)	1460029003000
Function	For car/vehicle transportation
Pay Load	For 5 cars (2 cars down deck, 3 cars upper deck)
Main Frame	3 50mm height I beam, Top Flange 1 0 mm, Middle Flange 6 mm; Bottom Flange 1 2 mm
Floor	3mm thickness
Axle	FUWA 2 axles X 13T
Traction Pin	JOST 3.5 " (90mm)
Suspension	Mechanical suspension
Landing gear	JOST 25 T
Tyre	11.00R2 2.5 (8 pcs)
Spare Wheel Carrier	One set of spare wheel & tyre carrier including a riser.
Braking systerm	Dual line-air brake, piggyback spring on all axles; four units of T30/30 spring brake chamber. four lifting hydro-cylinder. Three aircraft jump frames.
Electril System	One unit of JAEGER POWAY, 24V 7-pin ISO1185 standard socket; Standard Tail lamp with turn signal, brake light & refletor, Side lamp etc. One set of 6-core standard Cable
Painting	Sand blasting processing on rustproof protection. One coat of anticorrosive primer, two coats of finish urethane paint, Color as customer choice.

THE MAIN COMPONENTS OF THE WARRANTY PERIOD (SEE TABLE):

ITEM NAME				WARRANTY	ITEM NAME		WARRANTY
MAIN FRAME	FRAME			1 YEAR	RUNNING GEAR	AXLE	6 MONTHS
	SUSPENSION			6 MONTHS		AXLE BEARING	3 MONTHS
	KING PIN			1 YEAR		WHEEL HUB	3 MONTHS
	BALANCE ARM			3 MONTHS		TIRE	6 MONTHS
ITEM NAME				WARRANTY	ITEM NAME		WARRANTY
BRAKING DEVICE		BRAKE DRUM		3 MONTHS	SUPPORT DEVICE	LANDING GEAR	6 MONTHS
		BRKE CHAMBER		3 MONTHS		SPARE WHEEL CARRIER	6 MONTHS
		AIR RESERVOIR		6 MONTHS
ITEM NAME						WARRANTY
OTHERS			LEAF SPRING			3 MONTHS
			BRAKE CHAMBER DIAPHRAGM			3 MONTHS
			EMERGENCY RELAY VALVE			3 MONTHS
			BRAKE SHOE			3 MONTHS
			RELAY VALVE			3 MONTHS

FAQ
1. How do you transport the semi trailers
We will transport the trailers by bulk or cotainer,we have possess long-term cooperation with ship agency who can provide you lowest shipping fee.

2. Can you satisfy my spacial requirement?
Sure! We are direct manufacturer with 20 years experience and we have strong producing capacity and R&D capacity.

3. How can you guarantee quality?
Our raw material and OEM parts including axle, suspension,tyre are purchased centralized by ourselves,every part will be inspected strictly.Moreover,advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding quality.
4.Can I have samples of this type of trailer to test the quality?
Yes, you can buy any samples to test the quality,our MOQ is 1 set.

6. What's the delivery time and can you lower the price?
It depends on your order. The delivery time is 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.

7. Can I customize the painting and the logo?
Yes, we offer customized logo for any type.

8. What's the payment method?
TT 30% as Deposit, Balance Before shipment by TT or L/C at sight
